We think holistically.
SERVICES
We are your reliable partner for the design and manufacture of complex machines, complexes, sub-assemblies, single parts and serial parts.
YOUR PARTNER FOR MECHANICAL ENGINEERING IN BERLIN
Since 1978, the company H.-H. FOCKE GMBH & CO. KG domiciled in Berlin has been a successful and reliable partner for the machine building industry. On a surface of approx. 11,000 m², we develop and produce single parts as well as complex machine components for the packaging industry.
With over 300 employees, we are able to cover the complete value chain: starting from the development and design, through the manufacturing, up to the assembly. We employ only highly qualified expert staff in our mechanical and electrical assembly areas.
Our machine park comprising approx. 50 CNC machines is supplemented by 3 coordinate measuring machines allowing us to measure components parts with dimensions of up to 4,000 x 2,000 x 1,600 mm.
The use of state-of-the-art EDP systems like ERP, PPC and DCS allows us to ensure short lead times, process reliability and a high adherence to delivery dates.
As a company that has been certified according to ISO 9001, we guarantee the adherence to the highest quality standards.
Whenever you want to contract out the manufacture of complex single parts, serial parts or complete machines, we are your reliable partner.
THE PILLARS OF OUR SUCCESS
CORPORATE PHILOSOPHY
Services
DESIGN
We develop your product.
You have the idea – we have the engineers and design draftsmen.
Competences
- 3D/CAD design using Solid Edge
- Development of special machines as well as design to order
- Complex free-form modeling
- Consultancy regarding development
- Equipment design
- Electrical design
- Technical documentation and presentation
- Calculations
- Simulations
- 2D-/3D-Drawings
Machining
Mechanical production – with micrometer precision
Turning/milling centers and milling machines with 5-axes technology meet the highest accuracy demands. With our 50 up-to-date CNC machines, we manufacture single and serial parts for you. Here, pallet systems offer high efficiency and flexibility.
Competences
- MILLING
“3- to 5-axes machining centers, boring machines and portal milling machines” - TURNING
Complete machining on turning/milling centers - GRINDING
Flat, circular, curve and globoid grinding - WIRE ERODING
Surface treatment
Matt or glossy … polished or coated … according to your demands
We offer you a variety of different finishings for your surfaces.
Competences
- Slide grinding
- Glass bead blasting
- Wet painting
- Further surface treatments through associated companies
Assembly
Perfection down to the smallest detail.
On a surface of approx. 1,800 m², our technicians assemble individual components, subassemblies, machines and complexes. No matter whether it concerns mechanical or electrical assembly – we employ only highly qualified technicians for assembly. Another hall provides an assembly surface of 800 m² with gantry crane. Here, aggregates and machines can be assembled separately.
Competences
- Mechanical and electrical assembly
- Assembly of pneumatic and hydraulic systems
- Preassembly, final assembly and system assembly
- Control technology
- Programming (Beckhoff TwinCAT)
- Control cabinet construction
- Gear construction
- Joining technologies
- Commissioning (PacDrive, PNOZ, Lenze)
- Acceptance and documentation according to DIN VDE, DIN EN and IEC
Quality management
Quality at its best.
Quality management plays an important role for us. With our self-developed quality system (QUALIDAT), we monitor all procedures that are relevant to the quality of the product.
Competences
- Certified according to ISO 9001 since 2004
- Measurement protocols
- 3D component measurement as service
- Surface and material tests
- Three CNC coordinate measuring machines (by Leitz and Zeiss, respectively) in a fully air-conditioned measuring room
- FARO measuring arm
- Renishaw measuring sensors on all CNC machining centers
- Calibration of measuring devices
- Documented review of assembly steps
- Error management
- Initial sample inspection – inspection during production
- Self-inspection by workers and independent final inspection
Service
More than you expect.
Besides the aforementioned services, we offer you additional service features.
Competences
- Mechanical and electrical assembly service
- Inspection of machines
- Commissioning and test run of machines/complexes
- High- or low-voltage tests
- Inspection of portable electrical equipment
- Training for crane driving license and driving test
- Consultation and support concerning the construction of prototypes and pilot run production
MACHINE PARK AND FURTHER COMPETENCES
MACHINING
MILLING +
MACHINING CENTERS (3 TO 5 AXES) +
XYZ
Hermle C20 UP600450450
Hermle C30 UP650600500
DMG Mori DMC 65 H duoBlock700700700
DMG Mori DMC 80 H duoBlock800800800
DMG Mori DMC 80 U duoBlock8001,050800
DMG Mori DMC 100 U duoBlock1,0001,2501,000
DMG Mori DMC 160 U duoBlock1,6001,2501,000
DMG Mori DMC 635 V635510460
Grob G352600855750
Paths of travel | data in mm
LONG-BED MILLING MACHINES (3 OR 4 AXES) +
XYZ
DMG Mori DMF 1801,800700700
DMG Mori DMF 220*2,200560720
MG Mori DMF 250*2,500920820
*Linear | paths of travel | data in mm
BORING MACHINES +
XYZW
Grob BZ 16002,5001,6001,800
Wotan Rapid 13,5001,6001,250600
Waldrich Coburg MultiTec4,5003,5001,500
Paths of travel | data in mm
All machines are equipped with measuring sensor systems with optical signal transmission.
GRINDING +
EXTERNAL CYLINDRICAL GRINDING WITH IN-PROCESS MEASUREMENT +
LØ
Schaudt FlexGrind S 10001,000440
Maximum values
FLAT-GRINDING MACHINE WITH MAGNETIC TABLE +
XYZØ
Elb-Schliff BD101,000400600
aba easyGrinder 5500250420
G & N MPS 2 - R300100300
Maximum values
GLOBOID MILLING AND GRINDING MACHINE +
ZA
Kopp FSG21640440
Maximum values
WIRE ERODING +
XYZ
Mitsubishi FA 20S500350300
Paths of travel
Surface treatment
Slide grinding +
Walther Trowal circular and trough vibrators
Glass bead blasting +
MHG blast machine, air flow rate: 1,600 m²/h
Wet painting +
- On 600 m²
- 6 paint preparation booths
- Washing machine for up to 1,500 kg
- Painting room (24 m²) with adjacent drying room (20 m²), including heat recovery
Further surface treatments through associated companies +
- Tempering
- Nitriding
- Anodizing
- Electroless nickel-plating
- Black finishing
- TUFRAM® coating
Assembly
OF SUBASSEMBLIES, MACHINES AND COMPLETE COMPLEXES +
- On approx. 2,500 m²
- Mechanical & electrical assembly
- Assembly of pneumatic and hydraulic systems
- Pre-assembly, final assembly and system assembly
- Control technology
- Control cabinet construction
- Gear construction
- Joining technologies
- Precision measurement technology
- Gantry cranes (for up to 16t)
- Surface and cup wheel grinding machines are available
QUALITY MANAGEMENT
QUALITY ASSURANCE +
- 3 CNC coordinate measuring machines (by Leitz and Zeiss, respectively) in a fully air-conditioned measuring room, max. work piece size: 4 m x 2 m x 1.6 m
- QA department of 300 m² with various measuring machines, fully IT-assisted
- Certified according to DIN EN ISO 9001:2015
FURTHER FACILITIES
Laser marking +
Trumpf Laser VMC5 diode-pumped solid-state laser
Trumpf Laser TruMark 5050 ytterbium fiber laser
SAWING +
Square: W x HØ max.
Kasto Twin A2 band-saw260 x 260260
Behringer HBE 411A band-saw510 x 410410
Dimensions in mm
METALWORKING DEPARTMENT +
- On 600 m²
- Grinding and polishing workplaces, also for aluminum
- Joining technologies
- Gluing
- CNC box column drilling machine
- Marking plate
(4,000 mm x 2,500 mm) - Shaft straightening machine
- Rausch keyseating machine
CAREER
APPRENTICESHIP
Whether you are a pupil, student, woman or man, anyone who is interested in technology and mechanical engineering may apply for an apprenticeship in our company. You will get to know our complete company and become part of the Focke team. Each of our apprentices has the prospect of being hired later.
WE OFFER THE FOLLOWING APPRENTICESHIPS:
- Cutting machine Operator
- Specialist for system integration
- Office management assistant
WE OFFER:
- A diversified and varied apprenticeship place
- State-of-the-art technology
- Good pay
… and a super working atmosphere
“Well, I didn’t even know that Focke exists”, Mandy openly admitted. And she continued: “All the halls and machines are quite impressive.” Eugen, an apprentice as a cutting machine operator, added: “Focke is the roof over the head.”
Source: Hoxtell, Annette (2015), Entscheidungsgründe für den Ausbildungsbetrieb: Eine explorative Studie mit Auszubildenden sowie Schülerinnen und Schülern. Dissertation Wirtschafts- und Sozialwissenschaften, Universität Potsdam. Available at: https://publishup.uni-potsdam.de/opus4-ubp/frontdoor/deliver/index/docId/9337/file/hoxtell_diss.pdfPUPILS & STUDENTS
Pupils and students who wish to do an internship with us are welcome!
Girls'Day
For more than 10 years, we have participated in the nationwide “Future Day”. For more information, please refer to www.girls-day.de
CURRENT VACANCIES
Please have a look on our German website.
DIRECT CONTACT FOR CAREER:
H.-H. FOCKE GMBH & CO. KG
Auguste-Viktoria-Allee 15a, 13403 Berlin (Germany) – Phone: +49 30 41006-11 E-Mail: Regina.Bartout(at)focke.de
CONTACT
HERE YOU WILL FIND US!
H.-H. FOCKE GMBH & CO. KG, Berlin
Auguste-Viktoria-Allee 15a
D – 13403 Berlin
Germany
Phone: +49 30 41006-0
hh-info(at)focke.de
